Model number and main parameters
Model number | Voltage (VAC) | Frequency (Hz) | Phase | Power (W) | Current (A) | Speed (RPM) | Air flow (m3/min) | Noise (dBA) | Weight (kg) | Capacitance (μF/V) | Bearing | Related product |
200FZY1-D | 220 | 50 | 1 | 25 | 0.15 | 1200 | 6.5 | 60 | 2 | 2/450 | Ball bearing | |
200FZY2-D | 220 | 50 | 1 | 65 | 0.3 | 2300 | 13 | 70 | 2 | 1/450 | Ball bearing | Order |
200FZY3-D | 380 | 50 | 3 | 25 | 0.08 | 1200 | 6.5 | 60 | 2 | Ball bearing | ||
200FZY4-D | 380 | 50 | 3 | 65 | 0.18 | 2300 | 13 | 70 | 2 | Ball bearing | Order | |
200FZY5-D | 110 | 50 | 1 | 25 | 0.08 | 1200 | 6.5 | 60 | 2 | Ball bearing | ||
200FZY6-D | 110 | 50 | 1 | 65 | 0.6 | 2300 | 13 | 70 | 2 | 4/250 | Ball bearing | |
200FZY7-D | 380 | 50 | 1 | 65 | 0.18 | 2300 | 13 | 70 | 2 | 1/630 | Ball bearing | Visiting… |
200FZY12-D | 220 | 50 | 3 | 65 | 0.3 | 2300 | 13 | 70 | 2 | Ball bearing |
finglai General
Model number | 200FZY series |
External dimensions | 200x210x71 mm |
Motor type | Three-phase / single-phase squirrel cage general motor |
Leakage current | 0.5mA |
Dielectric strength | 1500Vac 50Hz for 1 min |
Protection degree | IP54 |
Rotary direction of Fan | Counterclockwise from front view |
