Description
Operating voltage range : 4.5 ~ 13.2 (V) DC DC
Rated voltage : 12.0 (V DC DC )
Current Rating : 0.56 ± 10% (AMP)
Input power : 6.72 (W)
Bearings : Sealed bearings oily (NMB patented reverse disassembly )
Fan speed : 40% 1400 ± 10% (RPM rotation )
70% 2450 ± 10% (RPM rotation )
100% 3500 ± 10% (RPM rotation )
(PWM temperature control speed , please refer to the motherboard manual settings in the motherboard BIOS under SMART FAN inside )
Wind : 40% 25.34 ± 10% (CFM)
70% 44.34 ± 10% (CFM)
100% 63.35 ± 10% (CFM)
Noise level : 40% 16.6 ± 10% (dBA)
70% 29.0 ± 10% (dBA)
100% 41.5 ± 10% (dBA)
Lifetime value : 40000 (hours hours / 25 ° degrees )
Material : PBT resin + 30 % glass fiber + VO grade flame retardant polyester material
Weight : 105 g ( gram )
Fan number 7
Size 92 (L ) × 92 ( width ) × 25 ( height) (mm mm )
Hole center distance : – Parallel Pitch 82.5mm / diagonal pitch 116.8mmInterface: 4-pin motherboard universal / compatible with 3-pin ( PWM motherboard supports motherboard supports gun thermostat )
Speed support
Motherboard supports PWM thermostat
