Description
[Brand]:ADDA
[MODEL]: AD1212UB-A73GL
[Dimension]: 120x120x25mm
[Rated]: DC12V
[Range]: DC7.0V-13.6V
[Power]: 0.50A
[Speed]: 2500 RMP
[Temperature range]:-10 … 70 °C
[Life expectancy]: L10 life expectancy at 25 ° c for 40,000 hours
[Bearing]: maintenance-free double ball bearing
[Direction of rotation]: air discharged from the bracket, facing the rotor counterclockwise
[Connection]: + Red-Black: yellow
[Maximum air volume]: 99.12CFM
[Protection]: fault-protected and locked-rotor locks flow protection
[Minimum air pressure]: 0. 72 Pa
[Noise index]: 15-43.3 dB (a)
[Material material]: glass-fibre reinforced plastic, PBT housings, PA leaves
[Function]: electronically commutated external rotor DC fan, full commutation electronic parts
Main features: intelligent PWM temperature controller (motherboard PIN must be 4-pin has this function) as in Figure
Property is brand new, it is for the new stock is mainly look there are some scratches, so when used 90% new price
