Description
Model Number: SPB17 Rated voltage: DC12V Rated current: 1.4A Rated power: 17W Maximum lift: 5.5 meters Maximum flow rate: 960L/H Pump interface: G1/4 Temperature range: ≤60°C Speed: 3000RPM Working noise: <60 dB Water pump line length: 60CM Life: >50000 hours Internal brushless permanent-magnet motor components with inner reference P2 are provided for internal drive. They are specifically tailored for water cooling systems. The overall square structure, compact size and strong performance provide sufficient circulating power for the system and maintain long-term stable operation. Since August 17, some product features have been upgraded. The upgrade contents are as follows: 1. The integrated wiring harness is changed to a separable plug-in wiring harness structure. 2. Increased the manual speed control function, the current set pump can either be manual speed control or PWM automatic speed control. The factory default is PWM mode. Activate the manual mode method: Turn the speed control switch clockwise to enter the manual speed control mode. Rotate counterclockwise to the end, that is, close the manual mode to enter the PWM automatic speed control mode. Acrylic cover material is more brittle, personal modification Do not over-tighten the screws and joints at the interface, it may lead to cracking at the thread The pump cover has built-in RGB lighting components and is compatible with LRC light control systems. The pump cover and the water tank can be freely combined and separated, and different lengths of the pipe body components can be purchased later for upgrade and modification
