Sale!

COOLING REVOLUTION 109E5724K502 17251 172x150x52mm 24V 1.30A double ball strong wind volume dc cooling fan

$95.00 $90.25

10 in stock

SKU: 32859179302 Category:

Description

Manufacturer’s part number: 109E5724K502 FAN 172X51MM 24VDC

SDCUT RBLS order quantity: 1.

Description: FAN 172X51MM 24VDC SDCUT RBLS.

Minimum order quantity: 1.

Part status: on sale.

Voltage – rated: 24VDC.

Size/size: rectangle/round – 172mm long x 150mm high.

51 mm width:

Air flow: 300.0 CF (8.50m3/min)

Static pressure: 0.976 inch water column (243.0pa)

Bearing type: ball.

Fan type: tube shaft type.

Features: –

Noise: 60 dB (A)

Power (W) : 31.2W.

The RPM, 4100 RPM

End connect: 2 leads.

Intrusion prevention: –

Working temperature: – 4 to 158 ° F (70 ° C) – 20 ~

Recognition: CSA, TUV, UR.

Weight: 1.7 pounds (771.1g)

Additional information

Brand Name

COOLING REVOLUTION

Air Volume

45CFM

Application

Computer Case

Power

3.6W

Bearing

Two Ball Bearing

Fan Speed Control

No RPM

Package

Yes

Type

Fan

Model Number

109E5724K502

Power Interface

2PIN

Fan Life

100000 hrs

Lines

2 Lines

Fan Size

Other

Noise

Other
