Description
Brand: DELLTA
Bearings: high precision dual ball
Model: PFB0948EHE;
Origin: Taiwan
Dimensions: 90 x 90 x 38MM
Voltage: DC48V;
Current: 0.26A
Mean time to failure (MTTF): 180000 hours
Rated power 12.48W
Interface mode: three red blue black
Features: overwhelming super long working life, 180000 hours average no fault time; no compromise of high accuracy and high quality parts structure.
Fan frame: injection molding, PBT + 30% glass fiber + VO grade flame retardant;
Fan: injection molding, PBT + 30% glass fiber + VO grade flame retardant;
Fan rotation direction: from the direction of the fan leaf to counter clockwise;
Operating temperature: -10 degrees Celsius to 70 degrees celsius;
Storage temperature: -40 degrees Celsius to 70 degrees celsius;
Bearing: high precision ball bearing;
Power range: rated power plus or minus 15%;
Insulation resistance: greater than 500000000000000 ohm;
Voltage resistance: sink current 0.5mA500V / 1 minutes;
Working life: 80000 hours at 25 degrees.
Scope of application: frequency converter, chassis, power supply, cabinet, industrial equipment, server and other high-end reliable heat dissipation
