Description
- Brand: Delta
- Fan models: FFB0412SHN
- Appearance size: 40 * 40 * 28 mm
- Rated voltage: DC12V
- Voltage range: DC7.0 V to 13.6 V
- The input power: 0.45 A
- Rated speed: 8700 R.P.M
- Temperature range: – 10..70 ° c.
- Expected life: 25 ° C L10 expected life of 50000 hours
- Bearing structure: double ball bearing without maintenance
- Direction of rotation: wind discharge from the scaffold, in the face of the rotor rotate counterclockwise
- Maximum air volume: 43 CFM
- Motor protection, overload protection, fault protection and locked-rotor lock flow protection
- The minimum air pressure: 110 Pa
- Noise index: 40 dB (A)
- Material material: glass fiber reinforced plastic, PBT, shell and PA blades
- Function description: the electronic commutator outer rotor dc fan, complete electronic commutation components
- Connection: 4 pin (with temperature control)
