Description
Size: 80×80*38mm
Brand: PAPST
Model: W2S076-AD01-67
Bearing structure: S: (double ball bearings)
Working voltage: 8-240V/110-1V
Current: 0.06A
Power: 12 (W)
Frequency: 50/60 (Hz)
Speed: 2650r/min
Air volume: 26CFM
Noise: 30 (dB-A)
Weight: 3 (g)
Framework: black baking aluminum alloy die casting anticorrosive and moisture proof structure;
Leaf: plastic leaves
Bearings: imported ball bearings with high accuracy, long life and low noise.
Insulation: enameled wire adopts B class insulation, and the temperature is 155 degrees Celsius.
Connection mode: wiring type.
Insulation resistance: 500 Mega or above;
• withstand voltage: leakage current 0.5mA. withstand voltage 1500V/min
Fan rotation: from the fan blade direction to counter clockwise;
Life expectancy: 50000 (hours)
Refurbished
